High-Speed Automated Filling and Sealing System for Tubes and Cartridges

High-Speed Automated Filling and Sealing System for Tubes and Cartridges

Packmate presents its premier High-Speed Automated Filling and Sealing System, a pinnacle of engineering designed for the precise and efficient packaging of high-viscosity materials such as sealants, adhesives, epoxies, and lubricants into tubes and cartridges. This system embodies over three decades of Packmate’s dedication to creating intelligent, turnkey packaging solutions for demanding industrial environments. Engineered for maximum operational uptime and consistent output, it guarantees leak-proof integrity, exact fill volumes, and uniform product quality, establishing itself as a critical asset for manufacturers aiming to scale productivity and uphold stringent product standards.

Product Features

The system integrates cutting-edge automation with robust mechanical design to deliver exceptional reliability and performance across continuous production cycles.

• High-Velocity Precision Filling: Engineered for rapid cycle times, the system dramatically increases production throughput while maintaining exceptional filling accuracy for both tubes and cartridges, effectively eliminating product giveaway and material waste.
• Broad Material Compatibility: Expertly handles an extensive range of viscous compounds, from silicone sealants and polyurethane foams to construction adhesives and epoxy resins, with quick-changeover features that minimize downtime between production runs.
• Advanced Hermetic Sealing Technology: Incorporates a precision sealing mechanism that creates a permanent, tamper-evident, and leak-proof closure, which is fundamental for ensuring product shelf life, safety, and end-user satisfaction.
• End-to-End Automation: Features a fully automated process encompassing container feeding, precise filling, reliable sealing, and smooth ejection. This seamless operation significantly reduces labor dependency and minimizes potential for human error.
• Intelligent Control Center: Operated via a user-friendly PLC with a color touchscreen HMI. This interface allows for intuitive parameter setting, recipe storage, and real-time monitoring of production metrics, machine status, and diagnostic alerts for proactive maintenance.
• Durable & Sanitary Construction: Built with high-grade stainless steel (SUS304) in all critical contact areas, ensuring long-term durability, ease of cleaning, and compliance with rigorous industrial hygiene standards.
• Integrated Quality Assurance Options: The system is designed to seamlessly integrate with optional in-line vision inspection systems and weight checkers, enabling 100% automated quality control and the automatic rejection of any non-conforming packages.

Technical Specifications

Product Application Fields

This versatile and high-performance automated packaging system is ideally suited for a broad spectrum of industries that require reliable, high-speed dispensing of viscous products. Its primary applications include:

• Construction & Building Materials: For packaging silicone sealants, polyurethane foams, acrylic latex caulks, construction adhesives, and waterproofing compounds.
• Industrial Adhesives & Sealants: For dispensing epoxy resins, anaerobic adhesives, threadlockers, gasketing materials, and industrial-grade bonding agents.
• Automotive & Marine: For filling lubricating greases, anti-seize compounds, undercoating materials, and automotive-specific sealants and adhesives.
• Consumer & DIY Products: For packaging household adhesives, general-purpose sealants, decorator’s caulk, and repair compounds sold in tubes and cartridges.
• General Manufacturing: For any production process requiring precise, high-volume filling of pastes, gels, or other semi-solid materials into tubular packaging formats.
