Packmate Premade Pouch Packaging Equipment
Packmate’s premade pouch packaging equipment is engineered for small to medium-scale production environments that demand exceptional efficiency, operational versatility, and uncompromising hygiene standards. This advanced system masterfully blends intuitive, user-friendly operation with a robust, fully mechanical transmission mechanism, enabling simple one-button start-up and swift bag changeovers. It delivers precise volumetric or gravimetric dosing, reliable and consistent heat sealing, and is designed for easy maintenance, ensuring uniform packaging quality across a wide array of pouch formats while maximizing production line productivity and uptime.
Product Features
High-Efficiency Mechanical Transmission System
The machine’s core is a fully mechanical drive system utilizing high-precision, imported Japanese cams and sophisticated lever mechanisms. This design guarantees exceptionally stable and smooth operation, extends the equipment’s service life significantly, and allows for effortless one-button initiation. Constructed with wear-resistant surfaces and heavy-duty components, the system is built to deliver reliable performance for decades with minimal routine maintenance requirements.
Hygienic and Reliable Sealing Operation
All components that come into direct contact with the product are fabricated from 304 food-grade stainless steel, ensuring compliance with stringent food safety regulations. Major electrical and pneumatic elements adhere to international quality standards from renowned brands. The integrated vacuum sealing system employs advanced zero-friction, zero-wear synthetic materials, guaranteeing consistently airtight and leak-proof package seals that fully meet modern hygiene and preservation requirements.
Versatile and User-Centric Design
This machine offers extensive versatility, supporting numerous premade pouch types including stand-up pouches, zipper bags, four-side seal bags, three-side seal bags, and paper bags. It automates the entire packaging sequence: bag picking, material feeding, precise weighing, sealing, and final unloading. The design incorporates quick-change parts and an intuitive control interface, drastically reducing changeover downtime and facilitating rapid adjustments for different production runs.
Technical Specifications
| Parameter | Specification |
|---|---|
| Equipment Materials | 304 Food-Grade Stainless Steel |
| Pneumatic Components | FESTO (Germany), SMC (Japan), Airtac (Taiwan) |
| Drive Method | Mechanical Transmission (Cam, Gear, Lever) |
| Applicable Product Materials | Roasted/Puffed Snacks, Powders, Granules, Liquids |
| Work Process | Bag Loading, Coding, Stretching, Feeding, Sealing |
| Sealing Method | Single and Double Heat Sealing |
| Packaging Speed | 35–60 Bags per Minute |
| Packaging Bag Material | Stand-up, Zipper, 3-Side Seal, 4-Side Seal, Paper, Composite Films |
| Bag Width Range | 60–160 mm |
| Filling Range | 10–1000 g |
| Total Power Consumption | 4.5 KW |
| Drive Power Supply | Three-phase 380V 50HZ |
| Machine Dimensions (L×W×H) | 2070 × 1630 × 1460 mm |
| Main Unit Weight | Approximately 1000 kg |
| Operating Environment | Temperature: 10–40°C; Humidity: 30–90% RH (Non-condensing); Free of Corrosive Gases |
Standard Customization Options
| Item | Specification |
|---|---|
| Bag Formats | Stand-up, Zipper, Four-Side Seal, Three-Side Seal, Paper, Composite |
| Filling Product Types | Powders, Granules, Liquids, Semi-Solids |
| Dosing Accuracy | High-Precision Dosing Adjustable per Specific Material Characteristics |
| Sealing Type | Single/Double Sealing, Heat Sealing |
| Control Options | Semi-Automatic, Fully Automatic with One-Button Start and Bag Change |
| Optional Features | Quick-Change Parts, Color Marking Systems, Vacuum Sealing Systems |
Product Application Fields
This premade pouch packaging machine is ideally suited for a diverse range of industries requiring efficient, hygienic, and high-quality packaging solutions.
Food & Beverage Industry: Perfect for packaging coffee beans/grounds, milk powder, tea leaves, spices, condiments, sauces, granular foods, and various snacks.
Pharmaceuticals & Nutraceuticals: Excellently handles powdered dietary supplements, herbal extracts, protein powders, and other functional food powders requiring precise dosing.
Tobacco & Nicotine Products: Suitable for modern oral nicotine pouches, stick packs for powders, and doypack formats.
Chemical & Industrial Products: Effectively packages granular compounds, detergents, powdered chemicals, and various industrial raw materials.
Its inherent versatility, combined with high-speed operation and consistent output quality, empowers manufacturers to manage diverse product lines efficiently while rigorously maintaining superior packaging integrity and stringent hygienic standards.
